Product instruction:
SOL AC Direct Round Series offer the great solutions for home, office and industrial applications.
The ideal fit for a variety of luminaires and can be used in wall and ceiling bulkhead fixtures.
Specification
| Part Number | CCT | CRI | QTY of LEDs | Input Voltage | Typ. Power | Typ. Flux | Typ. Efficacy | Dim. Type |
| SLAM-F015L56032W-XX |
2700/ 3000 |
>80 | 60 | 110/ 220 | 15 | 1725 | 115 | |
| SLAM-F018L56032W-XX | 18 | 1980 | 110 | |||||
| SLAM-F024L56032W-XX | 24 | 1250 | 105 | |||||
| SLAM-F015L56032P-XX |
4000/ 5000/ 6000 |
>80 | 60 | 110/ 220 | 15 | 1875 | 125 | |
| SLAM-F018L56032P-XX | 18 | 2160 | 2760 | |||||
| SLAM-F024L56032P-XX | 24 | 120 | 115 | |||||
| SLAM-P015L56032W-XX-D |
2700/ 3000 |
>80 | 60 | 110/ 220 | 15 | 2025 | 135 | 0-10V |
| SLAM-P018L56032W-XX-D | 18 | 2340 | 130 | |||||
| SLAM-P024L56032W-XX-D | 24 | 3000 | 125 | |||||
| SLAM-P015L56032P-XX-D |
4000/ 5000/ 6000 |
>80 | 60 | 110/ 220 | 15 | 2250 | 150 | 0-10V |
| SLAM-P018L56032P-XX-D | 18 | 2610 | 145 | |||||
| SLAM-P024L56032P-XX-D | 24 | 3240 | 135 | |||||
| Units | K | PCS | Vac | W | lm | lm/W |
Application
Horticulture
Uitraviolet
Marine light
